Description
Fonction 8MP 4K
Prise en charge de la détection des visages, de la détection humanoïde et de la personnalisation d’autres fonctions intelligentes ;
Résolution d’éclairage de la lumière noire HD 8.0MP, images claires et fines ;
Prise en charge de la réduction du bruit 2D/3D, dynamique numérique large ;
Compression vidéo avancée H.265 (compatible avec H.264), taux très faible, qualité d’image haute définition ;
Anti-foudre professionnel, conforme aux normes GB/T17626.5 et IEC61000-4-5 ;
Soutenir ONVIF, accéder à un tiers ;
Soutenir diverses surveillances mobiles (iPhone, Android) ;
|
OS |
Parameters |
|
|
kernel |
System |
Linux |
|
Processor |
Mstar |
|
|
Video |
Image sensor |
8MP Super Low illuminance COMS image sensor |
|
Video Codec |
H.265 main profile and baseline |
|
|
LEN |
3.7mm |
|
|
IR LED |
NA |
|
|
IR distance |
NA |
|
|
Support mobile phone |
All phone |
|
|
P2P |
PHONE,IE,P2P Client global Internet |
|
|
Video Resolution |
First stream:4K 8MP(3840*2160)@15fps/5MP(2880*1624)@25fps/4MP(2560*1440)@25fps/ 3MP(2304*1296)@25fps/2MP(1920*1080)@25fps can be set |
|
|
4K 8MP(3840*2160) |
||
|
Second stream:1280*720,800*448,704*576,640*360 |
||
|
Three stream:640*360/352*288 |
||
|
frame rate |
8MP:15fps,5MP:25fps,4MP:25fps,3MP:25fps,2MP:25fps |
|
|
Video compression |
32Kbits/S～12280Mbits/S |
|
|
Min.Lux |
Color>0.01 LUX B&W<0 LUX |
|
|
Store |
SD card |
NA |
|
Client/Browser |
Support |
|
|
Record |
Client |
support |
|
Browser |
Support |
|
|
SD CARD |
not Support |
|
|
Playback |
Client |
support |
|
Browser |
Support |
|
|
SD CARD |
not support |
|
|
SD Card |
|
not support SD card |
|
|
||
|
Audio |
Audio input |
Mic is builded in camera |
|
Audio output |
SNA |
|
|
Audio Codec |
G.726/G.711 |
|
|
Internet |
Internet face |
10Base-T/100Base-TX, POE |
|
Network Protocol |
TCP/IP,https,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP |
|
|
Access Protocol |
ONVIF |
|
|
Alarm |
Motion detection |
At most 4 respective regions |
|
Alarm linkage |
Alarm picture send E-mail, alarm images upload FTP server |
|
|
Snap |
Time snap |
Regular support capturing images to the FTP server |
|
safe |
User management |
Provide three levels of rights management (admin, user, guest), support to modify login user name and password |
|
Other |
Inter Power,consumption |
DC12V 2A/POE (The package does not provide a power adapter) |
|
Working temperature |
-40℃ ～ +55℃ |
|
|
Working Humidity |
10-95% |
Remarque : si vous avez besoin d’une alimentation POE, sélectionnez l’option AJOUTER POE. Si vous ne sélectionnez pas l’alimentation POE, il s’agit d’un câble normal
Compression vidéo avancée H.265 Travailler Avec NVR Pour Un Enregistrement Fiable 24 Heures Sur 24 Et 7 Jours Sur 7
